Panduit Right Angle Fitting for LD10 - Single Piece

Q: How many cables fit in this conduit?

A:
LD3 is the ideal size for

• 1-4 Cat5e (24 AWG) Cables


• 1-2 Cat6 (24 AWG) Cables


• 1 Cat6a (24 AWG) Cable


• 1-2 A/V RG6 Cables


• 1-5 (2 Strand) Fiber Optic Cables

LD5 is the ideal size for

• 5-7 Cat5e (24 AWG) Cables


• 3-5 Cat6 (24 AWG) Cables


• 2-3 Cat6a (24 AWG) Cables


• 2-3 A/V RG6 Cables


• 6-9 (2 Strand) Fiber Optic Cables

LD10 is the ideal size for

• 8-20 Cat5e (24 AWG) Cables


• 6-13 Cat6 (24 AWG) Cables


• 4-8 Cat6a (24 AWG) Cables


• 4-10 A/V (RG6) Cables


• 10-24 (2 Strand) Fiber Optic Cables

Q: Can I mix and match Panduit and ICC raceway products?

A: No you cannot. The sizes of the products are similar but not exactly the same. It is better to use all of the same manufacturing when installing your raceway system. We carry a wide variety from each manufacturer. You just have to decide which one fits your needs better.
