HD15 VGA Male Crimp Connector Kit - Plastic
SKU
1123
Crimp Connector, Pins, Plastic Hood, & All Hardware | Gold-Plated Contacts | Create Custom Pinout
Quantity Discount Pricing | ||||
---|---|---|---|---|
1-4 | 5-9 | 10-49 | 50-99 | 100+ |
$11.79 | $8.89 | $7.59 | $6.79 | $5.99 |
These HD15 VGA Male Crimp Connector Kits are used to change the connection type of a cable. They can easily be crimped to a custom length cable creating a durable connection for all applications. These connectors are made with high-quality materials to ensure durability and a long life. The kit includes the crimp connector, crimp pins, a plastic hood, and all hardware.
Features:
- HD15 VGA Male
- Crimp Type
- 15 Pins
- Tinned Copper Shell
- Nickel Thermoplastic Insulator
- Includes: Connector, Crimp Pins, Plastic Hood, & All Hardware
Write Your Own Review
Product Questions
does this come with the wire to pin / placement configuration instructions
Question by: Phil White on Mar 29, 2018, 1:59 PM
No, this does not come with instructions. Please look at the Resources tab for that information. Please contact customer service at 888-519-9505 or https://www.showmecables.com/help for more info.
Answer by: Jeff - ProductManagement on Mar 29, 2018, 2:09 PM
Pin | Name | Direction | Description |
---|---|---|---|
1 | RED | → | Red Video |
2 | GREEN | → | Green Video |
3 | BLUE | → | Blue Video |
4 | RES | RESERVED | |
5 | GND | Ground | |
6 | RGND | Red Ground | |
7 | GGND | Green Ground | |
8 | BGND | Blue Ground | |
9 | KEY | Key (No pin)/ Optional +5V output from graphics card | |
10 | SGND | Sync Ground | |
11 | ID0 | ← | Monitor ID Bit 0 (optional) |
12 | SDA | ← | I2C bidirectional data line |
13 | HSYNC or CSYNC | → | Horizontal Sync (or Composite Sync) |
14 | VSYNC | → | Vertical Sync which works also as data clock |
15 | SCL | ← | I2C data clock in DDC2 Monitor ID3 in DDC1 |
Features & Specs | ||
---|---|---|
Connector | Type of Connector? | HD15 VGA |
Gender | The gender of this connector? | Male |
Style | Type termination style of this connector? | Crimp |
Housing | What the connector housing is made with? | Plastic |
Form Factor | The Form Factor of the Connector? | Straight |
