Belden 8233A RG11 Triax Video cable is used in analog video appllications and can be used both indoor and outdoor. This cable is CMR rated, 75 Ohm, and sweep tested from 5 MHz to 4.5 GHz. Internally this cable is protected from RFI and EMI interference by an extra layer of insulation and a second conducting sheath. This also provides greater bandwith. The center conductor is made from 14 AWG solid bare copper.
Features:
75 Ohm
Riser Rated
14 AWG Solid Bare Copper Covered Steel Conductor
Dual Bare Copper Shields (95% and 80% coverage
FHDPE (Foam High Density Polyethylene) Insulation
Sweep tested from 5 MHz to 4.5 GHz
Indoor/Outdoor
Triax Video
Greater Bandwith and Rejection of Interference
Professional Grade
Foot Markings
Max Continuous Length: 1000 FT
Please note: All products that are bought per foot are non-returnable.
Any amount of cable you order above the maximum continuous length of 1000 FT will be sent in separate pieces.
