ECore RG11 Solid Copper Coax Cable - Black - Per Foot
SKU
80-110-520 BK
This item is subject to a 15% tariff surcharge
Per FT | 75 Ohm | 14 AWG | Shielded | PVC | CM Rated | Solid Copper Conductor | UL Listed
Per FT | 75 Ohm | 14 AWG | Shielded | PVC | CM Rated | Solid Copper Conductor | UL Listed
| Quantity Discount Pricing | ||||
|---|---|---|---|---|
| 1-49 | 50-499 | 500-749 | 750-999 | 1000+ |
| $0.35 | $0.31 | $0.30 | $0.29 | $0.26 |
The RG11 PVC coaxial cable is typically used for cable or satellite service. RG11 has an impedance of 75 ohms and is used for the longer runs or backboning premise wiring. This RG11 PVC cable features a solid 14 AWG copper center conductor with a 60% aluminum braid and 100% aluminum foil shield.
Features:
- Priced per ft.
- RG11
- PVC Jacket
- Impedance - 75 ohm
- Solid Copper center conductor
- Rated for indoor use
- UL-Listed
- 3 Ghz
- Max Continuous Length: 1000 FT
Please note: All products that are bought per foot are non-returnable.
Any amount of cable you order above the maximum continuous length of 1000 FT will be sent in separate pieces.
| Tariff Percentage | 15% |
|---|
Write Your Own Review
| Cable | Cable Type | Jacket | Inner Conductor Material | Inner Conductor Diameter (mm) | Dielectric | Outer Conductor (Shield) | Overall Braid | Bend Radius (mm) | Velocity of Propagation (%) | Dielectric Constant | Impedance | Capacitance | DC Resistance (loop) | Voltage Rating | Frequency Range |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 80-110-520 BK | RG11 | PVC | Cu | 1.63 | Foam PE | AL foil | AL wire | 120 mm | 85% | 1.4 | 75+/-3 Ohms | 53.2 pF/m | 30.43 Ohms | 60 VDC | 3 GHz |
| 80-110-560 BK | RG11 | PVC | CCS | 1.63 | Foam PE | AL foil | AL wire | 120 mm | 85% | 1.4 | 75+/-3 Ohms | 53.2 pF/m | 63.5 Ohms | 60 VDC | 3 GHz |
| 80-110-600 BK | RG11 | PE | CCS | 1.63 | Foam PE | AL foil | AL wire | 120 mm | 85% | 1.4 | 75+/-3 Ohms | 53.2 pF/m | 63.5 Ohms | 60 VDC | 3 GHz |
