RF Coax Cables

ShowMeCables RF coax cables are available with TNC, UHF, BNC, SMB, SMA, MCX, MMCX, N-Type, SSMA, SSMB, FME, Mini UHF, QMA, and NMO connector options, in male and female configurations. Straight and right-angle body styles come with bulkhead, 4-hole flange, and 2-hole flange mount options. Available with LMR-400, RG58, RG174, RG316, RG8, RG213, and other listed cable types. Impedance options include 50 Ohm and 93 Ohm, with frequency specifications up to 5.8 GHz and VSWR options from 1.35:1 to 1.6:1.

For a complete range of cable solutions beyond RF coax specifications, explore our Cables - Cat5e, Cat 6, Cat6a, Cat 7, Cat8, Telephone, Fiber, Audio/Video, Computer, Serial, Power, Wifi & Microwave category, covering additional cable types for network, data, and A/V connectivity applications.

Related Categories:

FAQs

What are RF coax cables used for?

RF coax cables are used for RF, wireless, antenna, measurement, test, telecom, and military applications. They are available with a wide range of connector types, including TNC, UHF, BNC, SMA, and N-Type, supporting signal transmission across diverse RF systems and test setups.

What connector types are available for RF coax cables?

RF coax cables are available with TNC, UHF, BNC, SMB, SMA, MCX, MMCX, N-Type, SSMA, SSMB, FME, Mini UHF, QMA, and NMO connector options. ShowMeCables also offers a wide range of connector combinations, such as SMA to TNC, N to BNC, and NMO to N, to interface between different connector standards.

What cable types are available for RF coax assemblies?

RF coax cables are available with LMR-400, RG58, RG178, RG174, RG196, RG316, RG223, RG400, RG142, RG188, RG393, RG316-DS, RG214, RG8, RG213, RG62, LMR-240, LMR-195, LMR-100, TFT-402, LMR-400 UltraFlex, and LMR600 cable types. This broad selection allows engineers to match cable type to the signal loss and flexibility requirements of their specific application.

What impedance options are available for RF coax cables?

RF coax cables are available with 50 Ohm and 93 Ohm impedance options. Matching connector and cable impedance to the system impedance is critical for minimizing signal reflection and maintaining performance across RF test and communication equipment.

What frequency range do RF coax cables support?

RF coax cables support frequency specifications up to 5.8 GHz. This range covers common RF, wireless, and antenna applications used across telecom, military, and test and measurement industries.

What VSWR ratings are available for RF coax cables?

RF coax cables are available with VSWR options including 1.35:1, 1.4:1, 1.5:1, and 1.6:1. Lower VSWR values indicate better impedance matching and reduced signal reflection, which is important for maintaining signal integrity in sensitive RF test and measurement applications.

What jacket materials are available for RF coax cables?

RF coax cables are available with PVC, polyethylene (PE), low smoke zero halogen (LSZH), and FEP jacket material options. These jacket choices support different installation environments, including applications requiring low smoke and halogen-free materials in the event of fire.

What mount types and form factors are available for RF coax connectors?

RF coax cable connectors are available with bulkhead, 4-hole flange, and 2-hole flange mount options, in bulkhead, bulkhead to right angle, right angle, right angle to right angle, straight, straight to right angle, and straight to straight form factors. These options support panel-mounted installations as well as cables requiring specific routing around equipment.

Need help selecting the right RF coax cable for your application? Our technical team provides support on connector type and combination selection (TNC, BNC, SMA, N-Type, and more), cable type compatibility (LMR, RG series), impedance matching (50 vs 93 Ohm), and jacket material selection for your specific RF, wireless, or test application.

Contact Sales: sales@showmecables.com
Product Technical Support: techsupportrf@infiniteelectronics.com

ShowMeCables offers RF coax cables in stock and ready to ship today. Our RF coax cables are available with male-male, female-female, male-female, male-open, and female-open gender configurations, along with PVC, polyethylene (PE), low smoke zero halogen (LSZH), and FEP jacket material options. These cables provide options for RF, wireless, antenna, measurement, test, telecom, and military applications.
